Directional Drone Jammer Security Protection for Drones Vehicles with RF Spectrum Analysis Drone Detection Alert System

1, Product Introduction

The device components can be quickly assembled and disassembled, supporting three operational configurations: vehicle-mounted, fixed, and portable. This allows for easy deployment and flexible use.

2, Functional highlight

3, Device Structure and Components

4,Product list

Device Name	QT	Weight
Equipment main unit	1	64.25 KG
Drone detection unit	1	30 KG
Drone control and management system	1
Power supply system	1	1.55 KG
Shield-type influence	5	6.85 KG
IPC or laptop	1
Software	1
Influence aviation case	1	15.55 KG
Detection aviation case	1	14.65 KG

Item	Parameters
Working mode	Radio Detection
Action Object	Drone Map Transmission, Flight Control Link
Operating Frequency	100Mhz~6Ghz
Detection distance	5KM-10KM (open and accessible areas)
Detection distance	2KM-5KM (urban complex electromagnetic environment)
Number of Simultaneous detections	≥10
Detection Refresh time	≤1.5S
Power Consumption	≤50W

Working mode	Radio interference
Action object	UAV map transmission, flight control link, navigation signal
Operating Frequency Band	Frequency Band (840~930)±15MHz (1535~1635)±15MHz (2380~2520)±15MHz (5130~5370)±15MHz (5725~5885)±15MHz (1080~1200)±15MHz
	Wattage (47±3)dBm (44±3)dBm (47±3)dBm (44±3)dBm (47±3)dBm (44±3)dBm
	Each frequency band can be controlled independently and combined as needed.
Influence Response time	≤3S
Suppression Distance Ratio	The maximum distance ratio between the system and the drone versus the drone and its controller should be no less than 15:1 in the absence of significant electromagnetic interference
Counter Distance	2km-8km
Countermeasure Band	6
System power consumption	≤2300W

Item	Parameters
Size	φH:850mm485mm
Weight	≤50kg
Protection level	IP65
High-Speed Operation	Capable of detecting and countering drones while in high-speed motion
Map Positioning	Equipped with an electronic map that can display the system's geographic location in real-time
Alarm Function	Provides alarm notifications via information, sound, and light upon drone detection
Working Temperature	-20℃~60℃+±2℃
Storage Temperature	-60℃~85℃+±2℃
System Power Supply	220V AC
System Interface	100/1000M Ethernet

Aviation case:
Influence aviation case dimension:470mm*570mm*710mm
Detection aviation case dimension:680mm×600mm×480mm

                                                               MYT Technology Introduction

 Chongqing Miao Yitang Technology Co., Ltd. is a specialized company engaged in anti-drone and unmanned intelligent defense management.

  With the technical support from the AI Internet of Things Research Institute of the Chinese Academy of Sciences and collaborations with multiple intelligent AI companies, the company has established research laboratories for AI unmanned field products, accumulating a variety of technical patents.

   The company's products are widely applied to unmanned automatic management solutions for various defense and perimeter areas, including AI anti-drone systems and AI unmanned vehicle patrol systems. These systems integrate with multiple technologies such as optoelectronics, radar, vibration, thermal imaging, facial recognition, and radio frequency management, truly achieving a 24-hour uninterrupted anti-drone defense and ground perimeter defense warning system. This allows for cost savings for clients, reduction in human resource allocation, and ensures the safety of clients' lives and property. The outstanding security system has won the company an excellent reputation and created higher value for its partners.
